Beschrijving
Mitsui warmtepomp 7Kw R32c Monoblock
Power supply V/Ph/Hz 220-240/1/50
Heating2
Capacity kW 8.40
Rated input kW 1.66
COP 5.05
Heating3
Capacity kW 8.20
Rated input kW 2.60
COP 3.15
Cooling4
Capacity kW 8.30
Rated input kW 1.71
EER 4.85
Cooling5
Capacity kW 7.40
Rated input kW 2.34
EER 3.15
Seasonal space heating energy effi ciency class6
LWT at 35 °C A+++
LWT at 55 °C A++
SCOP6
LWT at 35 °C 5.17
LWT at 55 °C 3.67
SEER6
LWT at 7 °C 5.19
LWT at 18 °C 8.09
Sound power level7 dB(A) 63
Outdoor fan Air fl ow m3/h 4500
Net dimensions (WxHxD) mm 1040×865×410
Packed dimensions (WxHxD) mm 1190×970×560
Net/gross weight kg 87/103
Water piping connections inch G1″BSP
Safety valve set pressure MPa 0.3
Total water volume L 5
Operating temperature range
Cooling °C-5~43
Heating °C-25~35
DHW °C-25~43
LWT range
Cooling °C 5~30
Heating °C 12~65
DHW °C 10~60
Refrigerant Type R32 (675)
Charged volume kg 1.25
Expansion valve Electronic
Backup electric heater Optional kW 3.00
Mitsui warmtepomp 7Kw R32c Monoblock
